Salice Компланарная система L70 FLEX ,ширина 2131-2530mm

Technical Information Coplanar two-door cushioned sliding system with adjustable track length. — load capacity 70 kg per door. Door Dimensions: Maximum door weight: 70 kg (evenly distributed). Width: – minimum 900 mm; – maximum 1700 mm. Height: – maximum 2700 mm. Thickness: – minimum 18 mm; – maximum 35 mm; – maximum 45 mm with handle. Clearance from floor: 33 mm. Material: a) wood or wood-based materials; b) glass with metal frame. Door Adjustment: vertical: ± 5 mm; horizontal: ± 3.5 mm; front: – upper part ± 4 mm; – lower part ± 3 mm.
